QU+ One

QU+ One with Open Source

The QU+ ONE 4k may be very small, yet it has enough power to play films in the highest resolution. A flat and sufficient CPU-memory that is installed is necessary to make this possible. The Quad Core Cortex-A53 CPU with 2.0 GHz 10bits 4K 60fps HDR10, Mali-450P2 GPU, 1 GB DDR3-memory and 8 GB NAND-Flash-memory make sure that everything runs smoothly.

The QU+ ONE 4K supports H.265 High Efficiency Video Encoding (HEVC).

Qu+ One

With the 4K HDR & 3D Android Smart TV Media Player you can enjoy thousands of exciting Apps, games, perfect picture quality for HDR with 10 Bit colour depth, ULTRA HD & 3D Full HD films as well as pictures, music and audio sound for true cinematic atmosphere.

You can all this directly play back from your external hard drive, external USB storage media or from your own network on TV. One of the leading Amlogic chip sets has been installed to make a smooth playback with 60 images per second (60fps) possible. Furthermore, the QU+ ONE has a HDMI 2.0 IN and HDMI OUT (looping in standby) connection and efficient WLAN antenna with 2,4GHz.

KODI is often inserted in digital media centers or mediahubs and is supported by many independent and voluntary developers over the world. The QU+ ONE appeals with providing a platform with an enormous selection of entertainment offers and a completely new television experience.

QU PLUS ONEDual boot enabled

Qu + One is the dual boot Media Player that comes with the Android operating system  6.01. An upgrade to Android 7.0 will be provided and can be downloaded from the website.

Alternative operating system is Open Source Linux with codes that can be downloaded from the website.

It contains special additives (plug-in) for Stalker and similar IPTV services.

Processor: CPU 32Bit AML S905X Quad Core A53 processor is an advanced application designed for OTT / IP set top box(STB) and the top of the media applications. A subsystem integrates powerful CPU / GPU, secured 4K video CODEC engine and the best HDR image processor with all the major peripheral devices.


System Resource: CPU-AML S905X
Powerful 3D graphics processor
H.264 1080P Full HD hardware decoding
H.265 HEVC 10bits 4K 60fps HDR10 & HLG HDR UHD Hardware Video Decoding
8GB eMMC-Flash
Built-in Wifi system
Hardware video decoding fully compatible with Full HD video
Widevine DRM supported (optional) / Playready DRM supported (optional) /
Verimatrix DRM is supported (optional)
NesTV for interactive multiscreen on smartphone and tablet
HTML5 is supported
Upgrade via OTA, USB, SD Card
Operating system Android 6.0 (update to Android 7.1) or KODI LibreELEC
Upgrade via USB or LAN / Internet
OSD Language Support: English,German,Franch,Italian,Spain….
Data exchange (backup and restore) with external USB memory
Low power consumption in standby


Chipset Amlogic S905X
Flash eMMC 8GB
Wi-Fi Built-in 802.11 b / g / n 2.4GHz (802.11ac 2.4G / 5G dual band optional)
Ethernet 100M Ethernet RJ-45

Video decoding H.265 HEVC MP@L5.0 to 1080P @ 60fps
H.264 AVC MP@L5.1 up to 1080P @ 60fps
H.264 MVC up to 1080P @ 60fps
MPEG-4 ASP @ L5 up to 1080P @ 60fps
MPEG-2 MP @ HL up to 1080P @ 60fps
MPEG-1 MP @ HL up to 1080P @ 60fps
RealVideo 8/9/10 up to 1080P @ 60 fps
WebM to VGA
Video file format support * .mkv, * .wmv, *. Mpg, *. Mpeg, *. Dat, * avi, *. Mov, * iso, * .mp4, * rm, * .jpg, * bmp, * Gif etc ...
Aspect ratio 4: 3 16: 9
Video resolution 1080p / i 720p 576i 480p
TOP Video resolution 4K (3840 x 2160 )@60fps

Audio decoding WMA, WMA Pro, WMV, MEPG, AAC, HE-AAC, OGG, OGA, FLAC, ALAC, Ape, M4A, RM, MPEG-1 Layer1 / 2, MPEG-2 Layer II, (Dolby Digital / Digital Plus (optional), DTS optional)
Audio Mode Mono / Stereo / Left / Right
document management
File system support NTFS, FAT32, EXT3, EXT4
File management Delete, rename, copy and paste

PowerQU Plus ONE unpacking
DC input range 5V / 2.0A
Power consumption Maximum 12W
Panel 2 * USB2.0, SD Slot
Rear Ethernet Connector, HDMI In, HDMI Out, DC IN,
Front Panel Standby, IR,
RCU IR RC3 (38kHz)
HDMI cable
DC adapter 1
Physical Properties
Operating temperature 0? -40?
Storage temperature -10? -65?
Size (WxDxH) in mm 96 * 96 * 12
IR RC3 (38kHz) NEC (2.4G / Bluetooth RCU optional)
Batteries (2 * AAA type), user manual (English, German)
